Eight chapters. Many overlapping histories.

An evolving history
of artificial intelligence.
1936 — now
And what comes after.

The Shape of Intelligence

Change the shape of an idea

A structure changed by experience.

Every generation imagines
intelligence in its own image.
This is how the shape changed.

Begin the story
An interactive sculpture by The Shape of Intelligence

An exhibition
by Jamie McKaye

First, we tried to
write the rules.

Then, we let the
examples speak.

And the question
changed shape.

Eight chapters in the history of an idea.
Enter at the beginning. Follow what changes.

01 / 08 The question1936 — 1956

Can a machine think?

A question of perspective

Same object.
A different reading.

An anamorphic sculpture. An open question.
01The question

Defining intelligence was part of the problem from the beginning.

Read this chapter
Listen to this chapterNarration, synthesised from Jamie McKaye's voice · 0:58 · the chapter text above is the transcript

Before anyone built a thinking machine, people argued about what thinking was. In 1936 Alan Turing described a machine that could carry out any procedure written as a finite list of steps, which gave "computation" a precise meaning. In 1943 Warren McCulloch and Walter Pitts wrote the nerve cell as a switch: add up the inputs, fire if the total crosses a threshold. In 1950 Turing set the argument aside with a test: if a machine can hold a conversation you cannot tell from a person's, call it intelligent. In 1955 four researchers proposed a summer study at Dartmouth on the conjecture that every feature of intelligence could be described precisely enough for a machine to simulate it. They named the field before they had a method. That order of events matters. The definition of intelligence was never settled first; it was rewritten each time a new method arrived.

02 / 08 The rules1956 — 1974

Therules.

How far could explicitly programmed reasoning take us?

An idea you can put to the test

Try the rules

6 rules · 7 junctions

  1. If it has a hole, it is a ring.
  2. If it has no straight sides and looks the same turned around, it is a circle.
  3. If it has three straight sides, it is a triangle.
  4. If it has four straight sides and sharp corners, it is a square.
  5. If it has more than four straight sides, it is a star.
  6. If it has no straight sides and sharp points, it is a crescent.

Pick a specimen to run it through the rules.

Add a rule

An educational illustration: a small rule system written for this exhibition, not a reconstruction of any historical program.

02The rules

Explicit instructions achieve impressive results and stay brittle.

Read this chapter
Listen to this chapterNarration, synthesised from Jamie McKaye's voice · 1:06 · the chapter text above is the transcript

The first working programs reasoned with symbols. In 1956 Allen Newell, Herbert Simon and Cliff Shaw's Logic Theorist proved theorems from Whitehead and Russell's Principia Mathematica by searching through possible steps. Rules seemed to be the way in: write down what an expert knows as conditions and actions, and let the machine apply them. Joseph Weizenbaum's ELIZA (1966) showed how far a short list of pattern rules could go, and how quickly people read understanding into it. A rival programme grew alongside. Frank Rosenblatt's perceptron (1958) learned its own weights from examples, and the Mark I perceptron machine set them with motors turning potentiometers. In 1969 Marvin Minsky and Seymour Papert showed the limits of a single layer, and neural approaches lost most of their funding for a decade. Rules were legible and brittle: every case had to be written down, and the world kept producing cases nobody had written.

03 / 08 The promise1973 — 1993

Thepromise.

Why did expectations repeatedly outrun results?

A promise takes shape.The work continues.

An imagined installation
03The promise

Progress and investment did not move together.

Read this chapter

Expectations ran ahead of results twice. In 1973 Sir James Lighthill's report for the British Science Research Council found that the field had not delivered on its promises, and funding in the United Kingdom fell away. In the 1980s expert systems revived the money: Digital Equipment's XCON configured computer orders with thousands of rules, and Japan's Fifth Generation project (1982) set out to build machines that reasoned. Companies were founded to sell hardware for the Lisp language. By 1987 that market had collapsed, and the phrase "AI winter" had been coined at a 1984 conference by people who saw it coming. Investment and progress did not move together. While budgets fell, small groups kept working: backpropagation for training multilayer networks was published in 1986, Yann LeCun's convolutional network read handwritten digits by 1989, and Gerald Tesauro's TD-Gammon learned backgammon from self-play in 1992. The quiet work was done in the cold.

04 / 08 The examples1986 — 2011

Theexamples.

What changed when machines learned from data?

An idea you can put to the test

Teach the machine

0 steps · training

Two blobs on the plate: no wire yet
● Group A○ Group B◌ Incorrect

Two blobs: 40 in tray A, 40 in tray B. Run the model to draw the wire.

Learned: the weights. Fixed: the two features (position on the plate), the model's shape and the objective (fewest wrong labels). A small real classifier trained here in the browser; not the capacity or architecture of every system in this chapter.

04The examples

Learning depends on examples, objectives and model capacity.

Read this chapter

Learning from examples means giving up on writing the rule. You choose a model with adjustable parameters, show it labelled examples, and move the parameters to reduce the error. A perceptron draws a straight boundary; a network with a hidden layer can bend it. Three things decide what gets learned: the examples, the objective the model is judged by, and its capacity to represent a boundary at all. Statistics supplied the method through the 1990s: support vector machines (1995), probabilistic models, and in 1998 the MNIST digit set that became the field's shared examination. Data grew with the web. ImageNet (2009) grew to more than fourteen million labelled images, labelled by people paid per task through Amazon's Mechanical Turk. A model that fits its examples has not been proved right; it has been fitted. What happens on the next example, from a slightly different world, is the question the examples cannot answer.

Inside the archive 24 events in this span

  1. 1995Support-vector machines
  2. 1998MNIST and LeNet-5
  3. 2009ImageNet
05 / 08 The scale2012 — 2016

The scale.

What became possible when methods, computing and datasets converged?

One unit becomes a system.

An impossible archive.An imagined installation

05The scale

Results emerge from several interacting ingredients, not one discovery.

Read this chapter

In 2012 a network called AlexNet, trained on two consumer graphics cards for about a week, cut the error rate in the ImageNet competition by a margin nobody had seen. Nothing in it was new on its own. Convolutional networks were twenty years old, the data was three years old, and the graphics cards had been built for games. What changed was that the ingredients met at the right sizes. Within four years the same recipe read speech, translated text and, in AlphaGo (2016), beat one of the strongest Go players in the world. Each result rested on things that are easy to leave out of the story: the people who labelled the images, the electricity and cooling for the machines, the benchmarks that decided what counted as progress, and the companies that could afford to run the experiment again. Results emerged from several ingredients interacting, and the ingredients had owners.

Inside the archive 21 events in this span

  1. 2012AlexNet wins ImageNet
  2. 2016AlphaGo beats Lee Sedol
  3. 2016Google reveals the TPU
06 / 08 The context2017 — 2021

The context.

How did attention and transformers change the picture?

Drag through the word.

“River” gives “bank” a geographical context: the land beside water.

An authored illustration of contextual meaning; not attention weights measured from a model. Words are shown whole rather than as model tokens.

06The context

Context shapes representations; prediction produces useful behaviour.

Read this chapter

In 2017 eight researchers at Google described the transformer, a network that reads a sentence all at once and lets every word attend to every other. Attention weights say which words matter for which. Training is simple to state: predict the next token, again and again, on more text than a person could read in a thousand lifetimes. What the model learns is a representation shaped by context: the same word means different things after different words, and the model's numbers move accordingly. By 2018 BERT set records across language tasks; in 2019 GPT-2 wrote paragraphs; in 2020 GPT-3, with 175 billion parameters, did tasks it had never been trained for when shown a few examples in its prompt. Prediction turned out to produce behaviour. Whether the model understands anything is a question people still argue about. What it does is measurable: a distribution over what comes next.

07 / 08 The interface2022 — present

The interface.

What happens when people can converse with generative systems?

Language becomes a way in.
Drag the seam. Change the distance.
07The interface

Fluent output, factual reliability and successful action are different properties.

Read this chapter

On 30 November 2022 OpenAI released ChatGPT, a conversational interface on a model tuned with human feedback, and by one estimate a hundred million people used it within two months. The interface changed who was in the conversation. Fluent text is not the same as true text: the same model that writes a working program will invent a court case that never happened, in the same confident sentences. A third property arrived with tools. Models that call a calculator, search the web or run code can act, and an action can succeed or fail separately from whether the words were right. Regulation followed the interface: the European Union's AI Act entered into force on 1 August 2024. By 2025 "agents" meant models running multi-step tasks with software of their own, and the argument moved from what the models could say to what they should be allowed to do.

08 / 08 The choicesAn open question

The choices.

The next
shape.

Choose where this goes.
Three paths. One unfolding form.
Choose the question you want to follow.

Who chooses what intelligence is for?

Who defines the goal? Which measures count as success? What gets left outside the frame?

08The choices

People still choose goals, deployment conditions and measures of success.

Read this chapter

The instruments in this exhibition were made by people who chose their goals. Rules were chosen for legibility, examples for coverage, prediction for scale. Each choice left something unresolved: cases nobody wrote down, examples nobody collected, outputs nobody checked. The choices ahead are of the same kind, and the technology does not settle them. Who decides what a model is for, and who answers for it when it acts? Which measures of success count: accuracy on a benchmark, harm avoided, energy used, people paid fairly for the data they produced? Should capability be released as fast as it is built? Researchers disagree in public about how much risk the current path carries, and the disagreements are worth reading in their own words. This is not a prediction of where the story goes. It is a fork with the paths unlit, and the lamps are held by people.
